Brand: Cosber
Model: C-VDSS-1
Measuring Mode: Dynamic & Non-Contact
Vehicle Measuring Range:
• Length: 0 – 25 meter
• Width: 0 – 5 meter
• Height: 0 – 5 meter
Accuracy: ±20mm
Repeatability: 99% to 99.2%
Vehicle Test Speed: < 10km/h
Measuring time: 30 seconds
Sensor Ingress Protection: IP65
Dynamic Vehicle 3-Dimensional Scanner
Product Description
• Automatically measure outer dimension (length, width and height) of vehicle via drive-through method
• Automatically measure wheelbase, front overhang, rear overhang and axle spread
• Highly accuracy using LiDAR technology
• Eliminate of the needs of manual measurement (time saving)
• Measured result will be store in local PC for future reference
• SIRIM calibration can be attained
